Two boards can look correctly spaced in CAD yet still fight each other at the connector, so stacking height, tolerance, and pin retention belong in one mechanical review.
Engineers working through these questions can download the published specifications for the Ximeconn s445 connector and raise sealing details with the supplier before tooling is fixed
An IP rating is a two-digit result from defined tests: the first digit covers solids, the second covers water, and higher water digits describe specific jet, immersion, or continuous immersion conditions with stated time and pressure.
Waterproofing a compact board-to-board connector is an assembly result built from mating surfaces, housing fit, and contamination control rather than from one molded part
This Ximeconn board-to-board waterproof hybrid connector adopts a 2+32 pin layout with 40A power rating, constructed with FR4 and PA9T inserts, and features an operating temperature range of -20°C to +105°C.
